TNK MP-1600A High-Temperature Physical Property Tester
TNK MP-1600A High-Temperature Physical Property Tester
The TNK MP-1600A High-Temperature Physical Property Tester, developed by Luoyang Turner High Temperature Instrument, complies with the national standard YB/T 186-2014 (Test Method for Melting Temperature of Continuous Casting Powder). Utilizing computer-aided testing technology, this automated equipment features scientific design, high automation, ease of operation, accurate results, excellent reproducibility, and minimal error. It integrates melting point and melting rate testing capabilities into a single device.
The human-machine interface supports multiple experimental configurations with one-button operation. Visual imaging technology replaces manual judgment, automatically determining slag temperature characteristics (melting point and melting rate). The system includes experiment replay, image browsing, and automated report generation.
Features
1、High Reliability
● Tubular furnace structure with silicon molybdenum rod heating, reaching up to 1600°C.
● Compact design, low heating power (2.5 kVA), and fast heating rate (40°C/min).
● Precise temperature control (±1°C), durable heating system, and low maintenance costs.
2、Advanced Automation
● PC-based interface for multi-channel parameter settings.
● Automated image tracking of sample height changes, adjustable image zoom, and result auto-save.
● Traceable experiment data with report generation.
3、Precision Software Design
● Independent temperature calibration systems for melting point and melting rate tests.
● 11-segment two-point calibration per system, minimizing errors.
4、Precision Mechanics
● 5-axis industrial camera and 6-axis sample stage for precise alignment.
● Ball screw sliding table with stepper motor control ensures consistent sample positioning.
● Lens shielding protects against high-temperature interference.
5、High Efficiency
● Post-experiment air cooling rapidly reduces furnace temperature, minimizing downtime.
6、Comprehensive Protection
● Self-diagnostic software with fault alerts for easy troubleshooting.
Main Technical Specifications
Parameter | Value/Description |
|---|---|
Rated Temperature | 1600°C |
Temperature Control Accuracy | ±1°C |
Heating Rate | 0–40°C/min adjustable |
Heating Element | Silicon Molybdenum Rods |
Weight | 200 kg |
Rated Voltage | 220V, 50Hz |
Rated Current | 20A |
Rated Power | 3 kW |
Feed Speed | 0–85 mm/s adjustable |
Dimensions (L×W×H) | 1200mm × 300mm × 500mm |
